Mindstorms NXT 2.0 (8547-1) is a NXT LEGO set released in 2009 with 621 pieces. Browse the parts list, minifigures, and verify loose bricks with our free scanner. This set includes 90 unique part types.
- → Read official LEGO build manuals on this page
- → Browse the full parts inventory
- → Verify loose bricks with our free part scanner
- → Check market value for parts and minifigs
Building instructions
2 official booklets — read on BrickID
BI 2002/ 2 - BATTERY INFO Building instructions · Format 5
Download size:
Checking download size…
Download size unavailable
Browse the instructions on your own terms.
Parts in this set
90 parts · page 1 of 2 · updating…
-
Cable, Connector, 20cm for NXT55804 · ×1 · Black -
Cable, Connector, 35cm for NXT55805 · ×4 · Black -
Cable, Connector, 50cm for NXT55806 · ×2 · Black -
Cable, USB, 2m for NXT57482 · ×1 · Black -
CD-Rom, NXT 2.04558560 · ×1 · [No Color/Any Color] -
![Hub, NXT Brick with Dark Bluish Gray Base [Complete Assembly]](https://cdn.rebrickable.com/media/parts/elements/4520887.jpg)
Hub, NXT Brick with Dark Bluish Gray Base [Complete Assembly]53788 · ×1 · Very Light Bluish Gray -
Large Figure Weapon, Zamor Sphere Holder53550 · ×2 · Pearl Dark Gray -
Large Figure Weapon, Zamor Sphere Launcher54271 · ×1 · Pearl Dark Gray -
Motor, NXT53787 · ×3 · Very Light Bluish Gray -
Playmat, Test Mat for Mindstorms NXT 2.04297447 · ×1 · [No Color/Any Color] -
Projectile, Large Figure Weapon, Zamor Sphere / Ball54821 · ×3 · Green -
Projectile, Large Figure Weapon, Zamor Sphere / Ball54821 · ×3 · Red -
Projectile, Large Figure Weapon, Zamor Sphere / Ball54821 · ×3 · Blue -
Projectile, Large Figure Weapon, Zamor Sphere / Ball54821 · ×3 · Yellow -
![Rubber Belt Small [15mm ID] [Round Cross Section]](https://cdn.rebrickable.com/media/parts/elements/4544140.jpg)
Rubber Belt Small [15mm ID] [Round Cross Section]85543 · ×2 · White -
Sensor, Colour, NXT 2.064892 · ×1 · Very Light Bluish Gray -
Sensor, Touch, NXT53793 · ×2 · Very Light Bluish Gray -
Sensor, Ultrasonic, NXT53792 · ×1 · Very Light Bluish Gray -
Sticker Sheet for Set 8547-186116 · ×1 · [No Color/Any Color] -
Technic Axle 123708 · ×1 · Black -
Technic Axle 2 Notched32062 · ×9 · Red -
Technic Axle 34519 · ×19 · Light Bluish Gray -
Technic Axle 3 with Stud6587 · ×6 · Dark Bluish Gray -
Technic Axle 43705 · ×4 · Black -
Technic Axle 532073 · ×8 · Light Bluish Gray -
![Technic Axle 5.5 with Stop [Rounded Short End]](https://cdn.rebrickable.com/media/parts/elements/4508553.jpg)
Technic Axle 5.5 with Stop [Rounded Short End]59426 · ×2 · Dark Bluish Gray -
Technic Axle 63706 · ×2 · Black -
Technic Axle 744294 · ×4 · Light Bluish Gray -
Technic Axle 8 with Stop55013 · ×4 · Dark Bluish Gray -
Technic Axle 960485 · ×2 · Light Bluish Gray -
Technic Axle and Pin Connector Angled #132013 · ×5 · Black -
Technic Axle and Pin Connector Angled #2 - 180°32034 · ×6 · Black -
Technic Axle and Pin Connector Angled #6 - 90°32014 · ×12 · Black -
Technic Axle and Pin Connector Perpendicular6536 · ×8 · Light Bluish Gray -
Technic Axle and Pin Connector Perpendicular 3L with 2 Pin Holes42003 · ×16 · Light Bluish Gray -
Technic Axle and Pin Connector Perpendicular 3L with Centre Pin Hole32184 · ×5 · Black -
Technic Axle and Pin Connector Perpendicular Double32291 · ×4 · Light Bluish Gray -
Technic Axle and Pin Connector Perpendicular Double Split41678 · ×8 · Light Bluish Gray -
![Technic Axle Connector Double Flexible [Rubber]](https://cdn.rebrickable.com/media/parts/elements/4198367.jpg)
Technic Axle Connector Double Flexible [Rubber]45590 · ×4 · Black -
![Technic Axle Connector Smooth [with x Hole + Orientation]](https://cdn.rebrickable.com/media/parts/elements/4512360.jpg)
Technic Axle Connector Smooth [with x Hole + Orientation]59443 · ×4 · Light Bluish Gray -
Technic Axle Connector with Axle Hole32039 · ×6 · Black -
Technic Axle Pin with Friction Ridges Lengthwise43093 · ×24 · Blue -
Technic Axle Pin without Friction Ridges Lengthwise3749 · ×4 · Tan -
Technic Axle Towball2736 · ×2 · Light Bluish Gray -
Technic Beam 1 x 11 Thick32525 · ×6 · Very Light Bluish Gray -
Technic Beam 1 x 11.5 Double Bent Thick32009 · ×2 · Dark Bluish Gray -
Technic Beam 1 x 11.5 Double Bent Thick32009 · ×4 · Light Bluish Gray -
Technic Beam 1 x 13 Thick41239 · ×10 · Very Light Bluish Gray
