Compact Crawler Crane (42097-1) is a Technic LEGO set released in 2019 with 920 pieces. Browse the parts list, minifigures, and verify loose bricks with our free scanner. This set includes 104 unique part types.
- → Read official LEGO build manuals on this page
- → Browse the full parts inventory
- → Verify loose bricks with our free part scanner
- → Check market value for parts and minifigs
Ad slot:
Building instructions
Official LEGO instructions — read on BrickID
Download size:
Checking download size…
Download size unavailable
Browse the instructions on your own terms.
Ad slot:
Parts in this set
104 parts · page 1 of 3 · updating…
-
Brick Round 1 x 1 diameter Tube with 90 Degree Elbow (2 x 2 x 1) and Axle Holes (Crossholes) at each end25214 · ×6 · Yellow -
Brick Round 2 x 2 with Axle Hole3941 · ×1 · Red -
Cone 2 x 2 x 2, Open Stud3942c · ×4 · Orange -
Cylinder Half 2 x 4 x 5 with 1 x 2 cutout85941 · ×2 · Light Bluish Gray -
![Dish 3 x 3 Inverted [Radar]](https://cdn.rebrickable.com/media/parts/elements/4179580.jpg)
Dish 3 x 3 Inverted [Radar]43898 · ×4 · White -
Hook with Towball30395 · ×1 · Dark Bluish Gray -
Plate 1 x 104477 · ×2 · Black -
Plate 1 x 43710 · ×1 · Black -
Plate 1 x 63666 · ×2 · Black -
Plate 1 x 83460 · ×3 · Black -
Plate Round 1 x 1 with Solid Stud6141 · ×4 · White -
Plate Round 2 x 2 with Axle Hole Type 1 (+ Opening)4032a · ×2 · White -
Plate Round 4 x 4 with Pin Hole60474 · ×2 · Black -
Sticker Sheet for Set 42097-151284 · ×1 · [No Color/Any Color] -
String Cord Medium Thickness (1mm) 150cm37597c150 · ×1 · Dark Bluish Gray -
Technic Axle 103737 · ×4 · Black -
Technic Axle 2 Notched32062 · ×15 · Red -
Technic Axle 34519 · ×37 · Light Bluish Gray -
Technic Axle 3 with Stop24316 · ×9 · Reddish Brown -
Technic Axle 4 with Stop87083 · ×9 · Dark Bluish Gray -
Technic Axle 532073 · ×18 · Yellow -
Technic Axle 5 with Stop15462 · ×2 · Reddish Brown -
Technic Axle 63706 · ×1 · Black -
Technic Axle 744294 · ×3 · Light Bluish Gray -
Technic Axle 83707 · ×3 · Red -
Technic Axle 8 with Stop55013 · ×4 · Dark Bluish Gray -
Technic Axle 960485 · ×5 · Yellow -
Technic Axle and Pin Connector Angled #132013 · ×1 · Dark Bluish Gray -
Technic Axle and Pin Connector Angled #2 - 180°32034 · ×2 · Black -
![Technic Axle and Pin Connector Block 4 x 3 x 2 1/2 [Linear Actuator Holder]](https://cdn.rebrickable.com/media/parts/elements/4528038.jpg)
Technic Axle and Pin Connector Block 4 x 3 x 2 1/2 [Linear Actuator Holder]61904 · ×1 · Dark Bluish Gray -
Technic Axle and Pin Connector Perpendicular6536 · ×18 · Dark Bluish Gray -
Technic Axle and Pin Connector Perpendicular 3L with 2 Pin Holes42003 · ×3 · Yellow -
![Technic Axle Connector Smooth [with x Hole + Orientation]](https://cdn.rebrickable.com/media/parts/elements/4519010.jpg)
Technic Axle Connector Smooth [with x Hole + Orientation]59443 · ×27 · Yellow -
Technic Axle Pin 3L with Friction Ridges Lengthwise and 1L Axle11214 · ×6 · Red -
Technic Axle Pin with Friction Ridges Lengthwise43093 · ×32 · Blue -
Technic Axle Pin without Friction Ridges Lengthwise3749 · ×2 · Tan -
Technic Beam 1 x 11 Thick32525 · ×11 · Yellow -
Technic Beam 1 x 11.5 Double Bent Thick32009 · ×4 · Yellow -
Technic Beam 1 x 15 Thick32278 · ×4 · Yellow -
Technic Beam 1 x 2 Thick with Pin Hole and Axle Hole60483 · ×3 · Orange -
Technic Beam 1 x 2 Thin41677 · ×16 · Red -
Technic Beam 1 x 3 Thick32523 · ×3 · Dark Bluish Gray -
Technic Beam 1 x 3 Thick32523 · ×6 · Yellow -
Technic Beam 1 x 3 Thin6632 · ×6 · Yellow -
Technic Beam 1 x 4 Thin32449 · ×8 · Dark Bluish Gray -
Technic Beam 1 x 5 Thin with Axle Holes on Ends11478 · ×4 · Black -
Technic Beam 1 x 7 Thick32524 · ×16 · Yellow -
Technic Beam 1 x 9 Bent (7 - 3) Thick32271 · ×2 · Dark Bluish Gray
